sl-firstboot is a set of batch scripts that allow you to modify a Raspberry Pi OS image so that it runs a bash script during or after the first boot of the image. It is designed to be used on a Windows machine.
There are two batch scripts, one to inject a bash script during the first boot, when the system is not yet fully up and running, and one to inject a bash script after the first boot, once the system is up and a network connection has been established. The first is useful if you want to make low-level changes early on, so these can take effect during boot. The later is useful if you want to make higher-level changes that required interacting with components not available until the system is fully up and running. In most cases, this second option is what you want.
sl-firstboot allows you to run a bash script during the first boot of a Raspberry Pi image through minimal changes to the FAT32 boot partition of the image.
When your script is run, the system is still booting up and many things are not available yet. Your script should be aware of this; in most cases, you will want to use sl-firststart to avoid this.
sl-firststart allows you to run a bash script after the first boot of a Raspberry Pi image through minimal changes to the FAT32 boot partition of the image. The script is run through a systemd service after network connection has been established.
When your script is run, the system is fully started and most services should be available, including network connectivity.
Download the latest version of sl-firstboot from the releases section of the GitHub repository.
On a Windows machine, insert a USB stick or SD card with a Raspberry Pi image that you want to run your script on. On the same machine, have a copy of your script ready. Then run one of these command:
sl-firstboot.cmd <USB drive letter> <path\to\your\script> sl-firststart.cmd <USB drive letter> <path\to\your\script>
For example, if you want the script my-boot-init-script.sh
in the current folder installed on a USB stick in the D: drive,
you would use this command:
sl-firstboot.cmd D: my-boot-init-script.sh
After running this command, the image will have been updated and it is ready to use on a Raspberry Pi.
These tools can use dos2unix.exe to automatically make sure all script files have unix-style line-breaks. This is not required, but you will have to make sure your scripts do not using Windows-style line-breaks. You can download dos2unix from the dos2unix webpage. More details on how to make sure it gets used can be found in the dos2unix section below.
sl-firstboot copies an initialization script
(sl-firstboot-init) onto the FAT32 boot partition of the
Raspberry Pi OS image. It also copies your script to the same partition (as
sl-firstboot-payload). It then modifies the
cmdline.txt file on this partition to change the
init= value, and add a command there to run the initialization
script when the device boots.
When the Raspberry Pi boots up it will:
sl-firstboot-init,When sl-firstboot-init runs, it will:
/bin/bash and exit, otherwisecmdline.txt on the boot
partition,If the payload script runs successfully, all changes made to the image by sl-firstboot will be reverted. Any changes made to the image by the payload script will remain. The system will reboot and continue to boot normally.
sl-firststart-init, renamed to
sl-firstboot-payload) onto the boot partition of the USB drive.
It also copies your script to the same partition as
sl-firststart-payload.
When the Raspberry Pi is first booted, sl-firstboot causes the
sl-firstboot-payload script (which is a copy of the
sl-firststart-init script) to be run.
When sl-firstboot-payload runs, it will:
sl-firststart-payload from the boot partition to
/usr/lib/sl-firststart service,sl-firststart service,userconfig.service (see below).After this, all changes made by sl-firststart/sl-firstboot to the boot
partition will be reverted and the system reboots. The root partition will
have the sl-firststart service and the
sl-firststart-payload script added. The system will continue
with booting normally. When the system has been booted and network
connectivity is established, the sl-firststart service starts.
The sl-firststart service will:
/usr/lib/sl-firststart-payload,/bin/bash and exit, otherwise/usr/lib/sl-firststart-payload,sl-firststart service,sl-firststart service.If the payload script fails, the remaining steps are not executed. This means the payload script will continue to be run every time the system boots. Once the payload script succeeds, the service and script are removed and will no longer be executed on start up.
The userconfig.service is disabled by sl-firststart as this
is the normal first start script for Raspbian OS, i.e. the script which asks
you to provide a username and password once your Raspberry Pi starts for the
first time. The payload script run through sl-firststart is expected to
replace this script, making it obsolete and potentially disruptive, as it
uses the same TTY.
sl-firstboot can dos2unix.exe to copy files to the USB drive and make sure the files have unix-style line-breaks. You can download dos2unix from this page by scrolling down to the bottom of the page and looking under the Ready-to-run-binaries heading. There you will find a Windows section with links to download zip files.
After downloading the right zip file for your system, extract the files
from the zip and make sure to either add the path of the extracted
bin folder to the PATH environment variable, or have the
dos2unix.exe file in the current working directory before you use
these tools.
The tools will let you know if dos2unix is used and warn you if dos2unix cannot be found.
A: Only if you haven't installed dos2unix.
^M?A: You are using a Bash script that contains Windows style line-breaks. Please install dos2unix and try again.
